Jumbo Coiler Double
Jumbo Coiler Double – High-Efficiency Dual Wire Coiling System
The Jumbo Coiler Double is a cutting-edge solution designed for high-volume wire coiling in industrial applications, especially in nail production. Featuring dual-coil capability, this machine ensures uninterrupted workflow by allowing seamless switching between coils, reducing downtime and increasing operational efficiency.
Engineered for high-speed precision, this coiler optimizes wire winding, ensuring consistent coil formation and minimizing material waste. The system’s automated tension control maintains optimal wire alignment, enhancing feed stability for downstream nail-making machines.
Built for long-term reliability, the Jumbo Coiler Double features a sturdy frame and intelligent controls for smooth operation. Its integration into existing production lines significantly boosts manufacturing efficiency, making it an essential tool for nail manufacturers requiring continuous wire feeding.
| Feature | DOUBLE-JC |
|---|---|
| Code | 71-5000 |
| Weight | 300 |
| Depth | 1 100 |
| Height | 800 |
| Width | 790 |
| Nail Diameter Range | 1,6 - 3,77 mm / 0.625" - 0.148" |
| Nail Length Range | 19 - 100 mm / ³/₄" - 4" |
| Electric Power | 3 kVA, 3P, 210 - 230 V, 50 - 60 Hz |
| Bobbin Inner Diameter | 32 - 85 mm / 1.26" - 3.346" |
| Bobbin Outer Diameter | Up to 380 mm / 14.961" |
| Nails Per Coil | Up to 3 000 pcs |
| Weight Kg Lbs | 300 kg / 700 lbs |
| Air Supply | 6 bar / 87 psi / (One 1/2" hose) |
